Anderton Slopeloc Retaining Wall System

A straightforward dry lay block system for facing retaining slopes.

What is Slopeloc?

Slopeloc is a dry laid concrete block system with a unique ribbed face appearance that can be built as a gravity wall, and therefore be easily erected by the DIY enthusiast or alternatively as a structural wall by more experienced installers. Slopeloc can be used domestically in garden retaining wall projects or on a larger scale in commercial applications for embankment repairs and situations where an aesthetic slope is required.

Features & Benefits

Unique economical alternative to vertical retaining walls
Professional indemnity backed design
All units less than 20kg
Proven block/grid connection
Choice of colours - bespoke colours available to order
Fast, efficient delivery

Special order colours: available subject to minimum quantity

An Introduction to Structural Products CPD

This CPD covers the three main Retaining wall products offered – Stepoc, Slopeloc & Keystone. It provides information on each of the systems, the way they can be used and case studies of previous projects.

Find out more

Slopeloc Block Dimensions

Product Code	Dimensions (mm) W x L x H	Weight (kg)	Pack Size	Exposed Face Area	Coverage	Colour
SLOPE01	245 x 300 x 125	16.5	72	0.0375m2	2.70m2	FLINT
SLOPE02	245 x 300 x 125	16.5	72	0.0375m2	2.70m2	YORKSTONE
SLOPE04	245 x 300 x 125	16.5	72	0.0375m2	2.70m2	SANDSTONE

Product Code	Dimensions (mm) W x L x H	Weight (kg)	Colour
SLOPECAP01	245 x 300 x 90	11	FLINT
SLOPECAP02	245 x 300 x 90	11	YORKSTONE
SLOPECAP04	245 x 300 x 90	11	SANDSTONE

View our BIM files

We have a wide range of BIM objects and are continuously developing our meaningful digital information, which you can then use for your Building Information Modelling (BIM) requirements.

View BIM Files

Slopeloc FAQs

Can I build a curved wall with Slopeloc?

What is the maximum height of wall that can be built without the use of geogrid?

How many Slopeloc blocks are there per m²?

How many Slopeloc blocks are in a pack?

How do I drain a Slopeloc reinforced earth structure?

What reinforcing grids can be used behind the wall?

What fill material can be used behind a Slopeloc block wall??

Do you offer a Design Service?
